AM-4214SD SD Hotwire airflow meter wth recording funtion

Category: Airflow meters

• Range :
   - Air velocity : 0.2 to 20.0 m/s
   - Air temperature : 0 to 50
   - Type K/J thermometer : -50.0 to 1300.0

FEATURES :
• Combination of hot wire and standard thermistor, deliver rapid and precise measurements even at low air velocity value.
• Slim probe, ideal for grilles & diffusers.
• Air velocity : m/s, Ft/min, Km/h, Knot, Mile/h,
• Air temperature (
, )
• Air Temp. used thermistor sensor, fast response time.
• Type K, Type J thermocouple thermometer.
• SD card capacity : 1 GB to 16 GB.
• LCD with green light backlight, easy reading.
• Can default auto power off or manual power off.
• Data hold, record max. and min. reading.
• RS232/USB PC COMPUTER interface.
• Separate probe, easy for operation of different measurement environment.


Sensor Structure :
      - Air velocity & Air flow : Tiny glass bead thermistor.
      - Air temperature : Thermistor.
Dimension :
      - Main instrument : 203 x 76 x 38 mm
      - Telescope Probe : Round, 12 mm Dia x 940 mm
