GW INSTEK GFG-8210

Features:

Frequency Range : 0.1Hz ~ 10MHz
Waveforms : Sine, Triangle, Square, Ramp, TTL and CMOS Output
External Voltage Controlled Frequency (VCF) Function
Duty Cycle Control with Signal Inversion Capability
Variable DC Offset Control
Two-Step (-20dBx2) and Variable attenuator
Built-In 6 Digit Counter with INT/EXT Function up to 150MHz/High Resolution
LIN/LOG Sweep Mode

Description:

10MHz Function Generator

Specification:

MAIN

Frequency Range 0.1Hz ~ 10MHz (8 Range)
Amplitude > 10Vpp (into 50Ω load)
Impedance 50Ω±10%
Attenuator -20dB±1dBx2
DC Offset <-5V ~ >5V (into 50Ω load)
Duty Control 15% : 85% : 15% ~ 1MHz Continue variable (square wave only)
Display 6 digits LED display

SINE WAVE

Distortion 1% typical
Flatness ±0.45dB (±5%)

TRIANGLE WAVE

Linear > 98% to 100kHz

SQUARE WAVE

Symmetry ±2%, 1Hz ~ 100kHz
Rise or Fall Time < 35nS

CMOS OUTPUT

Max. Frequency 2MHz
Level < 4Vpp ~ 14.5Vpp±0.5Vpp adjustable
Rise or Fall Time < 120nS

TTL OUTPUT

Level

> 3Vpp
Rise or Fall Time < 20nS
  1. VCF

Input Voltage 0V ~ 10V (100 : 1)
Input Impedance 10kΩ±10%

SWEEP OPERATION

Sweep/Manual

Switch selector

Sweep/Rate >100 : 1 ratio max. and adjustable
Sweep/Time 0.5sec. ~ 30sec. adjustable
Sweep/Mode Lin./Log. switch selector
Sweep/Out 0V ~ 10±1V

FREQUENCY COUNTER

INT./EXT. Switch selector
Range 0.1Hz ~ 10MHz (5Hz ~ 150MHz EXT.)
Accuracy Time base accuracy±1 count
Time Base ±20ppm(23° C ± 5° C)after 30 minutes warm up
Resolution The maximum resolution is 100nHz for 1Hz and 1Hz for 100MHz
Input Impedance 1MΩ // 150pF
POWER SOURCE AC115V/230V±15%, 50 / 60Hz
? ?

ACCESSORIES

? Instruction manual x 1
Power cord x 1
GTL-101 x 2
DIMENSIONS & WEIGHT 251(W) x 91(H) x 291(D)mm,
Approx. 2.2 kg
